Installation and Use

1. When there are changes in load during work, cylinders with sufficient output force should be selected;

2. Under high temperature or corrosive conditions, corresponding high-temperature or corrosion-resistant cylinders should be selected;

3. In places with high humidity, high dust, or water droplets, oil dust, or welding slag, corresponding protective measures should be taken for the cylinder;

4. Before connecting the cylinder to the pipeline, the dirt inside the pipeline must be removed to prevent dust and other debris from entering the cylinder;

5. The medium used in the cylinder should be filtered with a filter element of over 40um before use;

6. Due to the short front cover and piston of the cylinder, the general stroke should not be too large;

7. In low temperature environments, anti freezing measures should be taken to prevent moisture freezing in the system;

8. During the working process, the cylinder should avoid being subjected to lateral loads as much as possible to maintain its normal operation and service life;

9. If the cylinder is removed and not used for a long time, attention should be paid to surface rust prevention, and dust blocking caps should be added to the intake and exhaust ports. Special attention should be paid: the front and rear covers cannot be disassembled by themselves;

10. Installation and disassembly of C-type buckle:

10.1. When assembling and disassembling, it is necessary to use suitable pliers (C-type buckle installation tool) to ensure safety and avoid damage to the human body or surrounding machines caused by the C-type buckle flying out;

10.2. Ensure that the C-type retaining ring is installed in the groove of the body retaining ring before ventilation.

安裝與使用
1、 工作中負載有變化時，應選用輸出力充裕的氣缸；
2、 在高溫或者腐蝕性條件下，應選用相應的耐高溫或耐腐蝕性氣缸；
3、 在濕度大，粉塵多，或者有水滴、油塵、焊渣的場合，氣缸應采取相應的防護措施；
4、 氣缸接入管道前，必須清除管道內臟物，防止粉塵等雜物進入氣缸內；
5、 氣缸使用介質應經過40um以上濾芯過濾后方可使用；
6、 因氣缸前蓋及活塞均較短，一般行程不可選擇太大；
7、在低溫環境下，應采取抗凍措施，防止系統中的水分凍結；
8、氣缸在工作過程中應盡可能避免受側向載荷，以維持氣缸的正常工作和使用壽命;
9、氣缸拆下長時間不使用，要注意表面防銹，進排氣口應加防塵堵塞帽， 特別注意：前、后蓋不可自行拆卸；
10、C型扣環的裝拆：
10.1、裝拆時一定要使用合適的手鉗（C型扣環安裝工具）進行，確保安全， 避免因C型扣環飛出，對人體或周邊機器造成損害；
10.2、確保C型扣環裝入本體扣環溝槽后，方可通氣。
